Hardware plastic stainless steel laser engraving machine

|

The development of science and technology always comes from the needs of production. In order to meet the higher requirements of production, our technicians made some adjustments to this integrated machine according to the needs of production, and placed the computer display screen and the marking column separately. In this way, the column can be installed with a rotating chassis, which is convenient for the adjustment of the marking range, and can achieve a marking range greater than 180 degrees. For some products with large volume or irregular marking, It does not need to spend more money, but also can achieve a certain range of marking effect


Description

The column and display are installed separately
  1. The laser beam quality is good, the laser wavelength is 1064nm
  2. Air cooling
  3. The service life of the laser is about 100,000 hours maintenance-free
  4. The operating table is made of high-quality aluminum plate and comes with fixing bars。
  5. Genuine operating software, supports all computer systems

Technical Parameters

Model

CL-20F

Marking scope

100*100(200*200)mm

Power

20W(Option 30W/50W)

Laser sources

Fiber module

Laser Head

Scanning head

Laser

Raycus Laser

Minimal character

0.001mm

Marking speed

7000mm/s

Support format

PLT, BMP, DXF, JPG, TIF, AI etc

Repeated accuracy

<0.01mm

Software

Genuine EzCad software

Power supply

220V/ 50Hz/2kVA

Process Material

All kinds of metal and part of Non-metal Materials

Interface

USB
