CCD Visual positioning marking of hardware tools
For problems such as irregular marking in batches, feeding difficulties caused by fixture design and manufacturing, poor positioning, and slow speed, the CCD marking machine can solve the problems by capturing the positioning points in real time through an external camera. Realize automatic feeding, precise positioning and marking, greatly improving marking efficiency
Description
- marking process automation, fast speed, high efficiency, anti-counterfeiting effect is significant
- easy to operate, a wide range of applications, suitable for a variety of materials marking
- support automatic coding, variable text, serial number, batch number, date, all kinds of bar codes and two-dimensional code marking
- according to customer production line needs flexible modification
- Attached CCD visual positioning system
|
Technical Parameters |
|
|
Model |
CL-CCDF |
|
Power |
20W/30W/50W/60W/100W(Option) |
|
Cooling Mode |
Air Cooling |
|
Marking Speed |
8000mm/s-15000mm/s |
|
Laser Source |
Synrad/Coherent/Davi/Jingrui（Option） |
|
Minumum Line Width |
0.015mm |
|
Pulse Frequency |
1-25Khz/1-100Khz |
|
Minumum Character |
0.2mm |
|
Field Lens Brands |
Singapore Wavelength |
|
Laser Wavelength |
10.64μm |
|
Marking Area |
110*110mm / 140*140mm/ 175*175mm/210*210mm/300*300mm |
|
Environment |
5℃-45℃, clean or dust-free |
|
Control Card |
JCZ Brand EZCAD |
|
Power Supply |
AC220V / 110V plug |
|
Operating System |
Win XP /7/ 8/ 10 (32 bit, 64bit) |
|
Warranty |
1 year |
